Min. Naročilo:1 Piece/Pieces
Size: 10.1 inch
Brightness: 1000 nits
Contrast Ratio: 1000:1
Resolution: 1280*800
Operating Temperature: -10 - 50°C
Vgrajeni zunanji zasloni v majhni velikosti, 10,1 palčni TFT 1000 NITS LCD monitor. Vsebino, prikazano na zaslonu, je jasno razvidno v dobro osvetljenem okolju, lahko se uporablja z vsemi vrstami polnilnih pilotov, avtomatov za samopostrežne storitve, kioski in drugimi strežniškimi terminali.
Če imate druge potrebe, nas kontaktirajte, bomo prilagodili najprimernejšo rešitev za tekoči kristalni zaslon glede na vaše potrebe.
Vgrajena funkcija izdelka na prostem
10.1 "TFT LCD plošča
Ločljivost 1280*800
Uporabljena na prostem, svetlost od 500nitov do 1500 nit neobvezno
Kapacitivna plošča na dotik, prekrita z 2 mm kaljeno stekleno trdno in zanesljivo za vandalo
VGA HDMI DVI USB vmesnik
Visoko zmogljiva glavna plošča, 7/24 neprekinjeno delovanje
Podpora 12-24V široka napetost
Ultra tanek sprednji okvir 3 mm, idealen za vdelano montažo
Sprednja plošča IP55 nepremočljivo preprečevanje prahu
Obratovanje široke temperature: -10 - 50 ° C
|
Product specification |
|
|
LCD panel |
|
|
Panel size |
10.1" |
|
Resolution |
1280*800 or 1024*600 |
|
Support Color |
16.7M colors |
|
Brightness (cd/m²) |
1000 nits (can be customized) |
|
Contrast ratio |
1000:1 |
|
View angle |
80°/80°/80°/80° (R/L/U/D) |
|
Touch panel |
|
|
Touchscreen Type |
Capacitive Touch (10 points ) |
|
Surface Hardness |
7H |
|
Luminousness |
90% |
|
Touch Interface |
USB (RS232 optional) |
|
Touch response time |
2ms |
|
Working Life |
>50 million times |
|
OSD |
|
|
OSD control |
Brightness, contrast ratio, auto adjustment, H/V position, language select, etc. |
|
Support languages |
English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese, etc. |
|
Support OS |
Windows ,HDMI, Android, ect. |
|
Power Supply |
|
|
External Power Supply |
AC 100 - 240V, 50-60Hz |
|
Working voltage |
DC 12-24V |
|
Power consumption |
≤35W |
|
Enclosure |
|
|
Material |
Aluminum Alloy |
|
Color |
Black, Silver or customized |
|
VESA mounting |
75x75mm/100x100mm |
|
IP grade |
Front panel IP55 waterproof |
|
Operating Environment |
|
|
Temperature Range |
operating: -10 to 50°C, storage: -20 to 80°C |
|
Relative humidity |
operating: -5% to 95%, storage: -5% to 95% |
|
Packing Details |
|
|
Gross weight |
about 4kg |
|
Accessories |
Power adapter, VGA cable, USB touch cable, embedded screws |
|
Other |
|
|
Mounting |
embedded mounting screws |
|
wall mounting brackets (optional) |
|
|
desk stand holder (optional) |
|
|
Warranty |
1 year warranty |
|
Certificates |
CE, 3C, RoHS |
